TDUX - Inflatable Duct Seal, Size 100
Flexible and reliable wraparound inflatable sealing system for cables
Fast and easy to install or remove, even when water is flowing out of the duct
Independent of duct or cable ovality
Water and airtight up to 50 kPa (7 psi)
Environmentaly friendly, non-toxic and resistant to chemicals
Product Classification
Regional Availability EMEA
Product Type Cable duct seal
Product Series TDUX
Ordering Note When sealing more than two cables in a duct, seperate orderable TDUX-CL clips are to be used
Dimensions
Width 120 mm | 4.724 in
Length 482 mm | 18.976 in
Cable Diameter, maximum 90 mm | 3.543 in
Cable Diameter, minimum 45 mm | 1.772 in
Conduit Inner Diameter, maximum 110 mm | 4.331 in
Conduit Inner Diameter, minimum 75 mm | 2.953 in
Environmental Specifications
Installation temperature -5 °C to +40 °C (+23 °F to +104 °F)
Packaging and Weights
Included Inflatable bladder with sealing mechanism
Packaging quantity 10
Regulatory Compliance/Certifications
Agency Classification
CHINA-ROHS Below maximum concentration value
ROHS Compliant
UK-ROHS Compliant
