Korne FD10 outdoor distributor box
/The prices exclude vat/
Aftermarket end distributor similar to Krone/Schiederwerk KRONECTION Box A-10 (EVz 85, 6432 1 001-00), for 10 pairs (10 DA), outdoor use
This is an aftermarket product technically compatible with the Krone/Schiederwerk KRONECTION Box A-10.
Weatherproof surface-mounted distribution box for connecting or branching a 10-pair (10 DA) telecommunication or installation cable.
Includes a pre-installed LSA-PLUS connection strip (series 8/10).
The compact design and LSA-Plus quick-connection system allow easy and space-saving installation without soldering or special tools.
Sufficient internal depth for optional 8/10-series overvoltage protection module.
Technical data:
Capacity: 10 DA (10 pairs) via LSA 8/10 strip
Housing dimensions (W × H × D): 106 × 94 × 59 mm
Protection class: IP54
Color: grey-white (RAL 9002)
Material: Duroplast (GFK)
Temperature range: -30 °C to +80 °C
Wall mountable (screws included), pole mounting optional
Technically identical to the Krone KRONECTION-Box A-10 (6432 1 001-00).
