3M™ FTTH Wall Outlet 8686

Outlet for Simple Installation
The 3M™ FTTH Wall Outlet 8686 provides a transition point between incoming cable and building access points for residential or business fiber installations. The outlet is designed to house up to two SC-type connectors and is compatible with 3M™ No Polish Connectors Alternatively, an integrated splice holder houses up to two splices for pigtail termination. As an option, the 3M™ Volition™ RJ45 K5e or K6 jacks can be mounted in the center of the outlet for hybrid structures. This configuration allows obtaining similar dimensions to electrical and telephone outlets that are already installed.
The 3M™ FTTH Wall Outlet 8686 is compatible with round and FRP-type indoor drop cables with 30mm bend radius.

86 x 86 format      -    Direct connection to standard wall boxes
Two SC ports        -   Accepts standard SC simplex coupling
Snap on cover      -    No screws required to install cover
Fiber cable access points are in six locations on the outlet base as well as a center rear entry point -   Flexibility in cable entry location
30mm bend radius fiber/cable management Maintains fiber bend radius requirements for    -    G.652D type fiber
