RG59 95% - indoor-outdoor coaxial cable

305m/ drum

With 95% shielding, its high performance electrical conductive properties allow for lower power loss. RG 59 coaxial drop cables are an essential component of broadband networks, whether for digital transmission, cable TV or computer networks.

Structure

Internal conductor Copper-clad steel or copper wire Φ0.60mm
Insulation Physically foamed PE Φ3.66mm
1. External conductor Glued aluminium laminated strip
2. Outer conductor Al-Mg or copper alloy braiding
 sheathing : ≥60%
3. Outer conductor Aluminium laminated strip
Sheathing PVC or PE Φ6.20mm

Mechanical properties

Cable length 305m
Minimum bending radius 28mm
Tensile force 180N
Adhesion force >20N

Electrical properties

Apparent resistance 75±3Ω
Rated capacitance 54 pF/m
Propagation speed 81%
DC withstand voltage 2.5 kV
Insulation resistance ≥5000M Ω-km
Filtering attenuation ≥85@30~1000MHz dB
