With 80% shielding, its high performance electrical conductor properties allow lower power loss. RG 11 coaxial drop cables are an essential component of broadband networks, whether for digital transmission, cable TV or computer networks.
Structure
Internal conductor Copper-clad steel or copper wire Φ1.63mm
Insulation Physically foamed PE Φ7.11mm
1. External conductor Bonded aluminium laminated strip
2. Outer conductor Al-Mg or copper alloy braiding
sheathing : ≥60%
3. Outer conductor Aluminium laminated strip
Sheathing PVC or PE Φ10.16mm
Mechanical properties
Cable length 305m
Minimum bending radius 50mm
Tensile force 384N
Adhesion force >60N
Electrical properties
Apparent resistance 75±3Ω
Rated capacitance 54 pF/m
Propagation velocity 84%
DC withstand voltage 4.0 kV
Insulation resistance ≥5000M Ω-km
Filtering attenuation ≥95@30~1000MHz dB
