ED2 outdoor distributor box
/The prices exclude vat/
Aftermarket end distributor similar to Krone/Schiederwerk KRONECTION Box A-2 (EVz 83, 6430 1 002-00), for 2 pairs (2 DA), outdoor use
This is an aftermarket product technically compatible with the Krone/Schiederwerk KRONECTION Box A-2.
Weatherproof surface-mounted distribution box for connecting or branching a 2-pair (2 DA) telecommunication or installation cable.
Includes a pre-installed LSA-PLUS connection strip (series 8/2).
The compact design and LSA-Plus quick-connection system allow easy and space-saving installation without soldering or special tools.
Sufficient internal depth for optional 8/2-series overvoltage protection module.
Technical data:
Capacity: 2 DA (2 pairs) via LSA 8/2 strip
Housing dimensions (W × H × D): 106 × 94 × 59 mm
Protection class: IP54
Color: pearl white (RAL 1013)
Material: Plastic
Temperature range: -30 °C to +80 °C
Wall mountable (screws included), pole mounting optional
Technically identical to the Krone KRONECTION-Box A-2 (6430 1 002-00).
