Bi-directional indoor user amplifier

Backward Transmission
Frequency Range: 5-30 (65)MHz (or specified by user)
Rated Gain 15 dB
Flatness In Band: ±1 dB
Noise Figure ≤12 dB
Return Loss 16 dB
MAX Output Level 110 dBμV
Carrier to second order intermodulation ratio 52 dB
Carrier to Alternative noise ratio 2% / <2
Dimension 178(L) x 100 (W) x55(H)

It is specialized for construction of the network. High compact circuit and Aluminium-alloy, drawbench of surface. good index and fine outfit.
Adopt SOT-115 encapsulation RF module on access, reliable non- liner. Choose low-noise micro-wave push-pull circuit, small distortion and high S/N ratio.
ratio.
Set up EQ and ATT on the right place, more convenient of debugging. Small power consumption, high reliable, good performance and price
