3M Quante ID3000, 10 pair

The insulation displacement connection system is the result of further innovative development of 3M Telecommunications valued world-
class IDC contact technology.

The multiplicity of applications rages from medium- and large-sized communications distributors up to main distributors for analogue and
digital local exchanges.

The compact design facilitates miniaturisation which approaches technical limits and forms the basis of the considerably increased component packing density while simultaneously reducing the weight of the equipment. The modular design allows the user selective application of entire blocks or individual components.

The ID 3000™ system facilitates conventional assembly of disconnection blocks on the existing frame or a purely vertical modular assembly on ID 3000 profile rails. The modular design facilitates the fitting of dissimilar 8 pair and 10 pair disconnection elements on a profile rail. Thus each individual block size can be achieved. Individual disconnection elements can be subsequently replaced without difficulty: the cabling remains in-situ.

To round off the ID 3000™ system, 3M Telecommunications offers comprehensive overvoltage protection as well as an economical and
wear-resistant mounting tool, in addition to a wide range of accessories, such as test leads, disconnection plugs, etc.
