LC-APC 1xSM G.657.A2 optical drop cable 40m

Optical Fiber Parameters
Type: single mode (SM), G.657.A2

Low bend-insensitive, ideal for sealed and dense installations

Wavelength: 1310 nm & 1550 nm (installation and data transmission)

Max. attenuation: ≤ 0.4 dB/km @ 1310 nm, ≤ 0.3 dB/km @ 1550 nm

Cable Design
Outer jacket: Black, UV-resistant, HDPE (High-Density Polyethylene)

Resistant to moisture, UV radiation and chemicals

Hardened design to withstand mechanical stress (e.g. laying in the ground, protection against animal chewing)

3. Connector Type
LC-APC (Angled Physical Contact)

Green sleeve for identification

8° angled polishing, minimizes reflections (ORL < -60 dB)

DUPLEX (two strands if required), but this is a 1 strand (simplex) version

Mechanical Properties
External diameter: ~2-3 mm (light and flexible, easy installation)

Tensile strength: ≥ 100 N (for short-term loading)

Bending radius: ≥ 30 mm (static), ≥ 15 mm (dynamic)
