The outdoor coax TAP junction is a special cable distribution unit designed for the safe installation of outdoor junction points for coaxial cables (e.g. RG6, RG11). Its main purpose is to provide signal distribution and network expandability in a protected environment, while withstanding extreme weather conditions.
Technical Parameters
Components:
Material: cast aluminium
Protection level: IP65-IP68 (dust and waterproof)
Temperature range: -40°C to +85°C
Impedance: 75 Ω (according to coax standard)
Specifications:
Frequency range: 5-3000 MHz
Damping: <0,5 dB/junction
Echo attenuation: >20 dB
